Arista DCS-7280SR-48C6-M-F 48x 10GB SFP+ 6x 100GB QSFP F-B Airflow Switch
Arista DCS-7280SR-48C6-M-F 48x 10GB SFP+ 6x 100GB QSFP F-B Airflow Switch is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Delivery and Shipping
Delivery and Shipping
Add some general information about your delivery and shipping policies.
Arista DCS-7280SR-48C6-M-F 48x 10GB SFP+ 6x 100GB QSFP F-B Airflow ...
The Arista 7280R Series of #xed systems, including the 7280R, 7280RA, 7280R2, 7280R2A and the 7280R2K, are key components of the Arista 7000 Series portfolio of data center switches. The Arista 7280R Series are purpose built 10/25/40/100GbE systems built for the highest performance environments, and to meet the needs of the largest scale data centers and service providers They deliver scalable L2 and L3 resources and high density with advanced features for network monitoring, precision timing and network virtualization to deliver scalable and deterministic network performance while simplifying designs and reducing Opex. The 7280R capabilities address the requirements for modern networking and rich multi-media content delivery requiring a lossless forwarding solution in a compact and energy e"cient form factor.This switch is ideal for high-density data center environments and service provider networks that require robust performance, scalability, and security for modern networking demands.
Ports and Connectivity
- 48 x 10/25G SFP28 Ports: High-density Ethernet connectivity
- 6 x 100G QSFP28 Uplink Ports: For high-speed uplinks and interconnects
- Management Ports:
- 1 x RJ45 management port
- 1 x USB port for management access
- Supported Optics: Compatible with a range of 1G, 10G, 25G, 40G, and 100G SFP+ and QSFP28 transceivers
- Model Number : DCS-7280SR-48C6-M-F
- Condition : Seller refurbished
Performance and Capacity
- Switching Capacity: 1.44 Tbps
- Forwarding Rate: 1.2 billion packets per second (Bpps)
- Latency: Sub-microsecond latency for high-performance applications
- Deep Packet Buffers: 32 MB for lossless forwarding
Routing Protocols:
- Supports IPv4 and IPv6 routing
- OSPF, BGP, and static routing
- Layer 2 Features:
- VLANs, 802.1Q tagging, Spanning Tree Protocol (STP), and Link Aggregation Control Protocol (LACP)
- Layer 3 Features:
- ECMP (Equal-Cost Multi-Path Routing)
- Multicast routing with PIM (Protocol Independent Multicast)
- VXLAN (Virtual Extensible LAN) support for network virtualization
Security and Monitoring
- 802.1X authentication, ACLs, and MACsec support for data encryption
- Role-based access control (RBAC) for granular access control
- DDoS attack mitigation and storm control
Network Monitoring:
- In-band network telemetry (INT)
- sFlow support for traffic monitoring
- SNMP for management and monitoring
Power and Environmental
- Power Supply: Dual redundant, hot-swappable power supplies
- Power Consumption: Typical 120W, maximum 200W (depending on configuration)
- Operating Temperature: 0°C to 45°C (32°F to 113°F)
- Operating Humidity: 5% to 95% (non-condensing)
- Form Factor: 1U rack-mountable
Software and Management
- Operating System: Arista EOS (Extensible Operating System)
- Management:
- CLI (Command Line Interface), REST API, SNMP, and web-based GUI
- Integration with Arista CloudVision for network-wide orchestration and automation
- Automation: Full support for network automation and provisioning
Additional Features
- Modular Design: Supports flexible port configuration to meet various network requirements
- High Availability: Redundant power supplies and fans for continuous operation
- Energy Efficiency: Designed for low power consumption to reduce operational costs
