New Cisco C9500-24Y4C-E Catalyst C9500-24Y4C Switch 2X PSUs -Network Essentials

Quick spec of C9500-24Y4C-E-New

• Product Code : C9500-24Y4C-E
• Description : Cisco Catalyst 9500 Series high performance 24-port 1/10/25G switch, NW Ess. License
• Switching capacity : Up to 2 Tbps
• Forwarding rate : Up to 1 Bpps
• DRAM : 16 G
• Flash : 16 G
• Dimensions (H x W x D) : 1.73 x 17.5 x 18.0 in
• Rack units (RU) : 1RU

C9500-24Y4C-E-New Specification

• Switching capacity :Up to 2 Tbps
• Forwarding rate :Up to 1 Bpps
• Total number of MAC addresses :Up to 82,000
• Total number of IPv4 routes (Address Resolution Protocol [ARP] plus learned routes) :Up to 212,000 indirect + direct Up to 90,000 host/ARP
• Total number of IPv6 routes :Up to 212,000 indirect + direct Up to 90,000 host
• QoS ACL scale :Up to 16000
• Security ACL scale :Up to 27000
• FNF entries :Up to 98,000
• DRAM :16 GB
• Flash :16 GB
• VLAN IDs :4000
• Total Switched Virtual Interfaces (SVIs) :4000
• Jumbo frame :9216 bytes
• Power Supply Selection :C9K-PWR-650WAC-R or C9K-PWR-930WDC-R
• Dimensions (H x W x D) :1.73 x 17.5 x 18.0 in
• Rack units (RU) :1 RU
• Input voltage :90 to 264 VAC
• Operating temperature :32° to 104°F (0° to 40°C)
• Storage temperature :-4° to 149°F (-20° to 65°C)
• Relative humidity operating and nonoperating noncondensing :Ambient (noncondensing) operating: 5% to 90% Ambient (noncondensing) nonoperating and storage: 5% to 95%
• Altitude :Operation up to 13,000 feet at 40°C
• MTBF (hours) :336,780
