Juniper Networks MX204-HW-BASE / MX204-HWBASE-AC-FS 4 x 100g Ports

Overview

The MX204 is a router from Juniper Networks. This unit comes with the Junos operating system and includes 3 fan trays and 2 power supplies, making it an excellent choice for high-performance networking needs. The Juniper MX204-HW-BASE is a high-performance and versatile router designed for service provider and enterprise networks. The Juniper MX204-HW-BASE router provides an impressive mix of scale, performance, and automation capabilities in a compact form factor. It’s suitable for various network environments, including edge and metro Ethernet networking. This listing is for the hardware only. License NOT included.

Highlights

Interfaces Supported:1/10/25/40/100GbE: The router supports a wide range of interfaces, including these high-speed Ethernet

Junos OS: The router runs Junos operating system (Junos OS), enabling a wide range of business and residential applications and services.

Automation Capabilities: It also supports automation capabilities for efficient network management.

Compact Design: The MX204 router is compact, occupying only one rack unit (1U) of space.

Multiple routers can be stacked in a single floor-to-ceiling rack for increased port density.

Built-in Routing Engine: The router supports one built-in Routing Engine.

Power Options: It can run on AC or DC power.Each device has two dedicated power supply modules.

Cooling: Cooling is handled by three fan modules.

Port Configurations: The MX204-HW-BASE has four rate-selectable ports that can be configured as

100-Gigabit Ethernet ports or 40-Gigabit Ethernet ports, or each port can be configured as four 10-Gigabit Ethernet ports using a breakout cable.

Specifications

• Network Ports : 8x 10 Gigabit Ethernet SFP+
• Uplink Ports : 4x 100 Gigabit Ethernet QSFP28
• Firmware Version : Junos
• SSD : 2x 100GB
• Flash : 3x JNP-FAN-1RU Fan Trays Included (Front-to-Back Airflow)
• Power Supplies : 2x JPSU-650W-AC-AO Power Supplies Included - DC Options is JPSU-650W-DC-AFO
• DDR4 : 32GB
• Performance : 400 Gbps
• Rack Mounts : Included
• Model Number : MX204-HW-BASE
• Condition : NEW
