Cisco  |  SKU: A9K-8X100GE-L-SE-ref

Cisco A9K-8X100GE-L-SE ASR 9000 8 Port 100 GE Line Card

$6,000.00
Shipping calculated at checkout.


Delivery and Shipping

Add some general information about your delivery and shipping policies.

Free ground fedex or UPS shipping

Overview

The Cisco A9K-8X100GE-L-SE ASR 9000 Series 4-Port and 8-Port 100 Gigabit Ethernet Line Cards provide industry-leading high density with line-rate 100 Gigabit Ethernet ports for Cisco ASR 9000 Series Aggregation Services Routers. These high-capacity line cards address bandwidth bottlenecks caused by increased video-on-demand, IPTV, point-to-point video, Internet video, and cloud services traffic. A single 100 Gigabit Ethernet port can replace large 10 Gigabit Ethernet link aggregation bundles, simplifying network operations. These line cards support flexible interfaces, including 100 Gigabit Ethernet, 40 Gigabit Ethernet, and 10 Gigabit Ethernet modes. Additionally, they allow for power-saving mode to reduce consumption

Specifications

Chassis compatibility

Compatible with the Cisco ASR 9006, ASR 9010, ASR 9904, ASR 9906, ASR 9912 and ASR 9922 chassis

Port density

4-ports and 8 ports of 100 Gigabit Ethernet per line card

Ethernet

●  100-Gbps IEEE 802.3ba compliant
●  100 Gigabit Ethernet PHY monitoring
●  IEEE 802.x flow control
●  Full-duplex operation
●  Per-port byte and packet counters for policy drops; oversubscription drops; Cyclic Redundancy Check (CRC) error drops; packet sizes; and unicast, multicast, and broadcast packets

Performance

●  100-Gbps line-rate throughput per port

Options

Each line card is available as either a service edge optimized (enhanced QoS) or packet transport optimized (basic QoS) line card

Reliability and availability

Line card Online Insertion and Removal (OIR) support without system impact

Physical dimensions (H x W x D); weight

8-port 100 Gigabit Ethernet Line Card: 14.5 x 1.63 x 22.02 in.; 28 lb (est.) (368.3 mm x 41.4 mm x 559.3 mm; 12.7 kg)

4-port 100 Gigabit Ethernet Line Card: 14.5 x 1.63 x 22.02 in.; 28 lb (est.) (368.3 mm x 41.4 mm x 559.3 mm; 12.7 kg)

  • Module Type : ASR 9000 8-port 100GE LAN/WAN/OTN Packet Transport Optimized Line Card
  • Network Ports : 8x 100 Gigabit Ethernet QSFP28 (Requires CPAK optics which are not included)
  • Designed For : Cisco ASR 9000 Routers
  • Part Number : A9K-8X100GE-L-SE
  • Condition : Used
