Cisco AIR-AP3802I-B-K9 Access Point Aironet 3802 802.11ac 2.4/5 GHz

Overview

AIR-AP3802I-B-K9 is one of the Cisco 3800 Series Access Points. The Cisco Aironet 3800 Wi-Fi access points are designed for large enterprise organizations that rely on Wi-Fi to engage with customers. The 3800 series provides multiple gigabit uplink speeds of 2.5 Gbps and 5 Gbps in addition to 100-Mbps and 1-Gbps speeds. It also delivers new 802.11ac Wave 2 standard. Cisco Aironet 3800 Series Wi-Fi access points are highly versatile and deliver the most functionality of any access points in the industry. AIR-AP3802I-B-K9 is designed for Indoor, challenging environments, with internal antennas. Besides, it provides B regulatory domain.

Specifications

• • Product Code : AIR-AP3802I-B-K9
  • Antennas : Internal Antennas
  • Interfaces : - 2 Ethernet ports - 100/1000/2500/5000 Multigigabit Ethernet (RJ-45) - CAT 5e cabling - Higher-quality 10GBASE-T (CAT 6/6a) cabling - 100/1000BASE-T autosensing (RJ-45 - AUX port) - Management console port (RJ-45)
  • Features : - 4x4 MU-MIMO with three spatial streams - MRC - 802.11ac beamforming - 20-, 40-, 80, 160-MHz channels - PHY data rates up to 5.2 Gbps - Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx) - 802.11 DFS - CSD support
  • Regulatory Domain : B (B regulatory domain): - 2.412 to 2.462 GHz; 11 channels - 5.180 to 5.320 GHz; 8 channels - 5.500 to 5.720 GHz; 12 channels - 5.745 to 5.825 GHz; 5 channels
  • System : - 1024 MB DRAM - 256 MB flash
  • Dimensions (W x L x H) : 8.66 x 8.68 x 2.46 in. (22 x 22 x 6.25 cm)
  • Net Weight : 4.6 lb (2.09 kg)
  • Product Model Specification:AIR-AP3802I-B-K9
  • Antenna Type:Internal
  • Wireless Standard:802.11ac Wave 2
  • Wireless Configuration:4x4:3
  • CleanAir Support:Yes
  • mGig Support:Yes
  • Regulatory Domain:B
  • Max Data Rate:5.2 Gbps
  • Power over Ethernet:Yes
  • Security Features:WPA, WPA2, 802.1X, AES
  • Operating humidity:10% to 90% percent (noncondensing)
  • Operating Temperature Range:32° to 104°F (0° to 40°C)
  • Dimensions (W x D x H):8.66 x 8.68 x 2.46 in
  • Mounting Options:Ceiling, Wall, Pole
  • Supported WLAN Controllers:Cisco 3504, 5520, 8540 Series

Datasheet
