Cisco N9K-C93240YC-FX2 48x 25GB SFP 12x 100GB QSFP28 Back-to-Front Air Switch + Lan Enterprise service
Cisco N9K-C93240YC-FX2 48x 25GB SFP 12x 100GB QSFP28 Back-to-Front Air Switch + Lan Enterprise service is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Delivery and Shipping
Delivery and Shipping
Add some general information about your delivery and shipping policies.
Cisco N9K-C93240YC-FX2 48x 25GB SFP 12x 100GB QSFP28 Back-to-Front ...
Overview
Cisco Nexus 9300-FX2 series is an extension of Nexus 9300-FX series switches with higher bandwidth capacity. The switches offer a variety of interface options to transparently migrate existing data centers from 1-Gbps, and 10-Gbps speeds to 25- Gbps at the server, and from 10- and 40-Gbps speeds to 50- and 100- Gbps at the aggregation layer. The platforms provide investment protection for customers, delivering large buffers, highly flexible Layer 2 and Layer 3 scalability, and performance to meet the changing needs of virtualized data centers and automated cloud environments.
Specifications
- Product Code : N9K-C93240YC-FX2
- Ports : 48 x 1/10/25-Gbps and 12 x 40/100-Gbps QSFP28 ports
- Supported speeds : 1/10/25-Gbps on downlinks 40/100-Gbps on uplinks
- CPU : 4 cores
- System memory : Upto 24 GB
- SSD drive : 128 GB
- System buffer : 40 MB
- Fan Modules included: 5x NXA-FAN-35CFM-PE fan modules Blue
- Power supplies(up to 2) NXA-PAC-1100W-PE2 Blue
Lan Enterprise service Included
- Item :Cisco Nexus 9300-FX2 Series Switches
- Feature :Cisco Nexus 93240YC-FX2
- Ports :48 x 1/10/25-Gbps and 12 x 40/100-Gbps QSFP28 ports
- Supported speeds :1/10/25-Gbps on downlinks 40/100-Gbps on uplinks
- CPU :4 cores
- System memory :Up to 24 GB
- SSD drive :128 GB
- System buffer :40 MB
- Management ports :2 ports: 1 RJ-45 and 1 SFP+
- USB ports :1
- RS-232 serial ports :1
- Power supplies(up to 2) NXA-PAC-1100W-PI2
- Typical power (AC) :298W
- Maximum power (AC) :708W
- Input voltage (AC) :100 to 240V
- Input voltage (High-Voltage AC [HVAC]) :100 to 277V
- Input voltage (DC) :–40 to –72V
- Input voltage (High-Voltage DC [HVDC]) :–240 to –380V
- Frequency (AC) :50 to 60 Hz
- Fans :5x NXA-FAN-35CFM-PI fan modules RED
- Airflow :Port-side intake and exhaust
- Physical dimensions(H x W x D) :2.1 x 17.3 x 23.3 in. (5.3 x 43.9 x 59.1 cm)
- MTBF :365,610 hours
- Maximum number of Longest Prefix Match (LPM) routes** :896,000
- Maximum number of IP host entries** :896,000
- Maximum number of MAC address entries** :256,000
- Maximum number of multicast routes :128,000
- Number of Interior Gateway Management Protocol (IGMP) snooping groups :Shipping: 8,000 Maximum: 32,000
- Maximum number of Cisco Nexus 2000 Series Fabric Extenders per switch :16
- Maximum number of Access Control List (ACL) entries :Per slice of the forwarding engine: 5000 ingress 2000 egress
- Maximum number of VLANs :4096
- Number of Virtual Routing and Forwarding (VRF) instances :Shipping: 1,000 Maximum: 16,000
- Maximum number of ECMP paths :64
- Maximum number of port channels :512
- Maximum number of links in a port channel :32
- Number of active SPAN sessions :4
- Maximum number of VLAN’s in Rapid per-VLAN Spanning Tree (RPVST) instances :3,967
- Maximum number of Hot-Standby Router Protocol (HSRP) groups :490
- Number of Network Address Translation (NAT) entries :1,023
- Maximum number of Multiple Spanning Tree (MST) instances :64
- Flow-table size used for Cisco Tetration Analytics platform :64,000
- Number of Queues :8
