Juniper MPC5E-100G10G 2-Port 100GbE 4-Port 10Gb MPC5E Modular Interface Card

Overview:

The Juniper MPC5E-100G10G is a high-performance router line card designed for network environments that require fast and reliable connectivity. With its 2x 100GB QSFP28 ports, it offers ultra-fast data transfer speeds to handle bandwidth-intensive applications. This line card also features 4x 10GB SFP+ uplink ports, providing flexibility in connecting to various networking devices. The performance of the MPC5E-100G10G with a LAN-PHY mode is a per-port speed of up to 10.3125 Gbps, and WAN-PHY mode delivers an equally impressive rate at around (or precisely)9.95328 Gbps per port. This router line card's throughput capacity reaches an incredible level of about 240 Gbps by offering significantly improved efficiency in handling large traffic volumes without reducing speed or reliability. Juniper MPC5E-100G10G: Fixed 2x 100GbE and 4x 10GbE line card bundle with full scale L2/L2.5 and reduced scale L3 features, optional license permits up to 32,000 queues with HQoS.

Specifications

• Network Ports : 2x 100 Gigabit Ethernet QSFP28
• Uplink Ports : 4x 10 Gigabit Ethernet SFP+
• Performance : LAN-PHY mode - 10.3125 Gbps per-port, WAN-PHY mode - 9.95328 Gbps per-port
• Throughput : 240 Gbps
• Queues : 32,000 per-slot w/HQoS (requires optional license)
• Designed for : Juniper MX2000 Universal Routing Platform Series
• Model Number : MPC5E-100G10G
• Part Number : MPC5E-100G10G
• Condition : Seller refurbished
