NEW Cisco C9350-NM-8Y expansion module - 8 x 25G/10G/1G or 4 x 50G

Overview

The Cisco C9350-NM-8Y is a field-replaceable uplink network module designed specifically for Cisco C9350 Series Smart Switches. It provides flexible high-speed fiber uplink connectivity for enterprise campus, aggregation, and access-layer environments where scalable bandwidth and migration flexibility are required. The module supports eight SFP56-based interfaces operating at 1G, 10G, or 25G speeds, with the option to convert the top-row ports into four 50G interfaces for higher-capacity uplinks. Designed for modern enterprise workloads including Wi-Fi 6/7, 5G integration, video collaboration, and high-density access deployments, the C9350-NM-8Y enables organizations to scale bandwidth without replacing the switch platform.

Specifications

• Model: Cisco C9350-NM-8Y
• Product Type: Field-replaceable uplink network module
• Supported Platform: Cisco C9350 Series Smart Switches
• Port Configuration:
  • 8 × SFP56 ports operating at 1G / 10G / 25G
  • Alternative mode: 4 × 50G ports
• Default Operating Mode:
  • 8 × 1/10/25 Gigabit Ethernet ports enabled
• Alternative Port Mode:
  • 4 × 50 Gigabit Ethernet on top-row ports
  • Bottom-row ports become inactive in 50G mode
• Maximum Aggregate Bandwidth:
  • Up to 200 Gbps
• Interface Type:
  • SFP28 / SFP56-based uplink interfaces
• Supported Ethernet Speeds:
  • 1 Gigabit Ethernet
  • 10 Gigabit Ethernet
  • 25 Gigabit Ethernet
  • 50 Gigabit Ethernet
• Deployment Use Cases:
  • Enterprise campus access uplinks
  • Distribution and aggregation connectivity
  • High-density wireless infrastructure
  • Data-intensive applications and IoT environments
• Scalability Features:
  • Migration path from 1G → 10G → 25G → 50G without switch replacement
• Installation Type:
  • Hot-swappable / field-replaceable module
• Compatibility Notes:
  • Designed exclusively for Cisco C9350 switches and not intended for legacy Catalyst network module slots.
