NOB Dell Networking Z9332F-ON 32P 400GbE QSFP56-DD Switch
NOB Dell Networking Z9332F-ON 32P 400GbE QSFP56-DD Switch is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Delivery and Shipping
Delivery and Shipping
Add some general information about your delivery and shipping policies.
The Dell Z9332F-ON Z-Series 32x QSFP-DD switch offers a high-speed networking solution with up to 32 ports of ultra-fast 400GbE connectivity. With a switching capacity of 25.6 Tbps and a forwarding rate of up to 5.1 Tpps, this switch can efficiently handle modern data centers' demands. The MAC address table size is ample at 8,000 entries, while the generous packet buffer size of 64MB helps ensure smooth traffic flow even during peak usage times. With sub-700ns latency, this switch delivers rapid performance for time-sensitive applications in large-scale networks without compromising reliability or speed.
- Model Number : Z9332F-ON
- Network Ports : 32x 400 Gigabit Ethernet QSFP-DD
- Port Supported Speeds : 100/400 Gbps - up to 32 ports of 400GbE (QSFP56-DD) or up to 128 ports of 100GbE or up to 144 ports of 10/25/50GbE (using breakout cable)
- Management Ports : 1x RJ45 Serial Console, 1x Gigabit Ethernet RJ45, 1x USB
- Switch Version : OS10 Enterprise Edition
- AirFlow Direction : Front-to-Back Airflow (I/O Panel to PSU Airflow)
- Fan Modules Included : 1x Fan Module Included
- Fan Module Options : 7x Fan Module Slots
- Power Supplies Included : 2x AC PSU's Included - Front-to-Back Airflow (I/O Panel to PSU Airflow)
- Power Supply Options : Back-to-Front Airflow option is available
- Switching Capacity : 25.6 Tbps (full duplex)
- Forwarding Rate : up to 5.1 Tpps
- MAC Address Table Size : 8,000
- Max IPv4 LPM Routes : up to 400,000 (ALPM)
- Multicast routes : 4,000 (Multicast IPv6 Routes)
- Virtual interfaces (VLANs) : 4,000 (Layer 2)
- Packet Buffer : 64MB
- Latency : sub 700ns
- Condition : NOB
