A10 Networks Thunder 6435 ADC Application Delivery Controller TH6435 | Tested

Thunder 6435(S) TPS Specifications

Performance

• Throughput: 152 Gbps
• Packets Per Second (Legitimate Traffic): 55 Million pps

Mitigation Performance

• Software-Based SYN Authentication: 55 Million pps
• Hardware-Based HW SYN Cookie: 220 Million pps
• Hardware-Based Anomaly Flood Blocking: 220 Million pps
• Maximum Monitored Sessions (Asymmetric Deployment): 64 Million

Network Interfaces

• 1/10 GbE Fiber (SFP+): 16 ports
• 40 GbE Fiber (QSFP+): 4 ports
• 100 GbE: None
• Management Ports:
  • 1 × Ethernet Management
  • 1 × RJ-45 Console Port

Hardware Specifications

• Processor: Intel Xeon Dual 12-core
• Memory (ECC RAM): 128 GB
• Storage: SSD
• Hardware Acceleration: 4 × FTA-3, SPE
• SSL Security Processor (S Models): 4
• Hardware Bypass: External

Physical

• Dimensions (H × W × D): 1.75" × 17.5" × 30"
• Rack Units: 1U
• Weight: 39 lbs

Power

• Power Supply: Dual 1,100W Redundant Power Supplies
• Power Efficiency: 80 Plus Platinum, 100–240 VAC, 50–60 Hz
• Power Consumption (Typical / Maximum): 620W / 710W

Environmental

• Heat Output (Typical / Maximum): 2,116 / 2,423 BTU/hr
• Cooling: Hot-swap Smart Fans
• Operating Temperature: 0°C to 40°C (32°F to 104°F)
• Operating Humidity: 5%–95%

Compliance

• Certifications: FCC Class A, UL, CE, TÜV, CB, VCCI, CCC, BSMI, RCM, EAC, NEBS, RoHS
